Fan nozzle design characteristics
H/U series nozzle can produce high impact of liquid column is the feature of flow or fan-shaped spray, jet Angle 0 ° to 110 °.
This kind of nozzle spray uniform distribution, droplet size is small to medium.When need to overlap several nozzle spray, characteristic of the edge of spray distribution evenly spray coverage.
H - VV and H - VVL series general fan nozzle at 3 bar pressure low rate is less than 3.9 liters/min, with outer pipe nipple.In the order number to DT alternative VV can provide inside pipe nipple.H - VVL said inside the nozzle filter (including pipe nipple without filter).
H - U and U series general fan nozzle pressure, the rated flow rate of 3.9 litres/minute or more, with the outer pipe nipple.By DU instead of U in the order number can be provided with internal thread pipe joint of H - 1/8 of an inch and a quarter inch U series nozzles.
The general application
Low cooling and quenching
Low product washing
The low water cooling
Low air and gas purifier
Low cleaner
Low liquid cleaner
Low dust control
Low fire
